Monitor Your Equipment With TPI USA Products

When it comes to vibration analysis and condition-based monitoring solutions, Reliability Concepts has what you need from TPI USA to keep your machinery operating at its peak efficiency. We are trained on all the products we sell so you know exactly how to get the most from your equipment purchase.

TPI Model 9070 Smart Vibration Analyzer

The TPI Model 9070 provides simple-to-use vibration monitoring and analysis for your machinery. Enjoy an easy display of vibration signals and automatic performance of vibration analysis functions to diagnose machinery faults such as unbalance, misalignment, and looseness.

Features for the TPI Model 9070 include:
  • ISO built-in alarms
  • BDU reading to easily identify bearing problems
  • 800 line FFT (Spectrum)
  • Ruggedized IP67 case
  • 3-year limited warranty
  • Full-color OLED display
  • Built-in band filters to easily identify problems (1X unbalance, 2X misalignment, 3X looseness)
  • Built-in accelerometer with stinge — optional long stinger and magnetic mount available
TPI Model 908-EX

TPI Model 9080-EX

The PI Model 9080-EX provides safe and simple vibration analysis. With its smart trend meter, it records, analyzes, and displays vibration signals with a single button for instant data.

Other features include:
  • Data collection
  • Trend data using VibTrend Software
  • Intrinsically safe cable mounted accelerometer with magnet
  • Built-in Bluetooth communication capability
  • USB docking station to download to PC
  • ISO built-in alarms
  • Easily identify bearing problems with BDU Reading
  • Easily identify problems with built-in band filters: 1X (unbalance), 2X (misalignment), 3X (looseness)
  • 800 line FFT (Spectrum)
  • Listen to bearing noise with optional Bluetooth headphones
  • Ruggedized IP67 case
  • 1-year limited warranty

Smart Vibration Monitor 9034 and 9038

The Smart Vibration Monitor 9034 and 9038 Online / Fixed Vibration units are single low-cost unit monitors for your plant. They monitor local alarms, connect to PC analysis software, and connects you to cloud-based monitoring and analysis software for better data collection and protection for your machinery.

Other features include:
  • Extremely cost effective – lowest cost per channel industrial vibration monitor / analyzer
  • Very easy to set up using Smart Vibration Monitor PC software
  • 24/7 monitoring of critical plant operations
  • 4 accelerometer channel and 8 accelerometer channel options
  • 24 VDC (relay drive) switched output for each channel (warning / critical, g, or velocity)
  • 4 to 20mA output for each channel (g or velocity)
  • Temperature input
  • Tacho output
  • USB for connection to Smart Vibration Monitor PC Software
  • Ethernet socket for connection to Online Vibration analysis software
Call Us Today for More Information or to Place an Order!
800-997-4467
